RADIO FREQUENCY IDENTIFICATION

From concept to installation to deployment, the sales engineers at Cobblestone Tag & Label stand ready to assist you every step of the way. RFID applications are becoming more prevalent in today's business environment and our engineers, partnered with the industry's best solutions providers are finding ways to overcome the challenges of this new technology. Every day new applications are being launched to streamline business processes. We offer a complete line-up of hardware, software and media solutions to meet the demands of this exciting new technology. Here's a little more about RFID---- A radio-frequency identification system uses tags, or labels attached to the objects to be identified. Two-way radio transmitter-receivers called interrogators or readers send a signal to the tag and read its response. The readers generally transmit their observations to a computer system running RFID software or RFID middleware.

RFID systems typically come in three configurations. One is a Passive Reader Active Tag (PRAT) system that has a passive reader which only receives radio signals from active tags (battery operated, transmit only). The reception range of a PRAT system reader can be adjusted from 1-2,000 feet. Thereby allowing for great flexibility in applications such as asset protection and supervision. Another configuration is an Active Reader Passive Tag (ARPT) system that has an active reader, which transmits interrogator signals and also receives authentication replies from passive tags. Finally, there is the Active Reader Active Tag (ARAT) system in which active tags are awoken with an interrogator signal from the active reader. A variation of this system could also use a Battery Assisted Passive (BAP) tag which acts like a passive tag but has a small battery to power the tag's return reporting signal.

RFID tags can be either passive, active or battery assisted passive. An active tag has an on-board battery and periodically transmits its ID signal. A battery assisted passive (BAP) has a small battery on board and is activated when in the presence of a RFID reader. A passive tag is cheaper and smaller because it has no battery. Instead, the tag uses the radio energy transmitted by the reader as its energy source. The interrogator must be close for RF field to be strong enough to transfer sufficient power to the tag. Since tags have individual serial numbers, the RFID system design can discriminate several tags that might be within the range of the RFID reader and read them simultaneously.

Tags may either be read-only, having a factory-assigned serial number that is used as a key into a database, or may be read/write, where object-specific data can be written into the tag by the system user. Field programmable tags may be write-once, read-multiple; "blank" tags may be written with an electronic product code by the user.

The tag's information is stored electronically in a non-volatile memory. The RFID tag includes a small RF transmitter and receiver. An RFID reader transmits an encoded radio signal to interrogate the tag. The tag receives the message and responds with its identification information. This may be only a unique tag serial number, or may be product-related information such as a stock number, lot or batch number, production date, or other specific information.RFID tags contain at least two parts: an integrated circuit for storing and processing information, modulating and demodulating a radio-frequency (RF) signal, collecting DC power from the incident reader signal, and other specialized functions; and an antenna for receiving and transmitting the signal.

Fixed readers are set up to create a specific interrogation zone which can be tightly controlled. This allows a highly defined reading area for when tags go in and out of the interrogation zone. Mobile readers may be hand-held or mounted on carts or vehicles. For more information concerning RFID applications, media or specifics, contact your Cobblestone Sales Consultant Today.
